TALARIA STING R MX4
Talaria created the Sting to bring cutting-edge electric performance to all riders. The MX4 features a lightweight frame, powerful mid-mounted IPM motor, 60V/45Ah battery and 120 km (78 mile) max range. Feel instant torque through the Sting’s intelligent gearbox and extremely quiet drivetrain. Further highlights include 4-level regen braking, a compact, well-balanced chassis and overall low maintenance.
All these features and more make the Talaria Sting R MX4 an ideal electric bike for experiencing the passion and thrill of off-road adventures.
HIGHLIGHTS
STING MX4: BUILT FOR YOUR NEXT ADVENTURE
-
NEW FOR 2024
-
Black rear brake disc guard, pegs, mount, wheel spokes & sprocket
- KEY FEATURES
- 45Ah battery: Best-in-class range and battery life
- Internal gearbox delivers quiet, reliable power (no more breaking/wearing out belts)
- Regenerative braking (can be adjusted easily via display screen for optimum performance)
- Fast charging time (3 hours)
- Improved battery connector (2023)
- 220mm brake rotors
- Improved DC IPM motor (2023), 94% efficiency
- Rear brake disc guard
- 125 amp circuit breaker
MSRP: $5,999.99 CAD
Destination and preparation charges: $249.99
WARRANTY
ONE-YEAR limited warranty
Talaria will cover all material costs associated with repairing or replacing any part or accessory found to be defective in material under normal use and maintenance. This limited warranty extends only to the initial retail purchaser. This limited warranty is in effect for 1 year from the initial retail sale date a new Talaria model from an authorized dealer.
Tech Specs
VEHICLE
Chassis Material
Process Method
Surface Method
Headlight
Front Fork
Rear Shock
Wheel Size
Tires
Max Range
Net Weight
Vehicle Dimensions
Seat Height
Wheelbase
Handlebar Length
Ground Clearance
6061 T4 & T6 aluminium alloy
Forged under 6,000 tonnes of pressure
Anodizing
LED
Fastace or Talaria Factory
Fastace/HT/Talaria Factory
19 in. front/rear
FR 70/100-19 / RR 80/100-19 off-road tires
100 km @ 25 km/h (62 miles @ 15 mph)
66 kg (145 lbs) with battery
1,880 x 770 x 1,088mm (74 x 30.3 x 42.8 in)
840mm (33.1 in)
1,250mm (49.2 in)
760mm (29.9 in)
300mm (11.8 in)
MOTOR
Motor type
Mounting Position
Weight
Motor Ext. Diameter
Peak Efficiency
Air-cooled DC IPM
Mid-mounted
7.0 kg
180mm
94%
CONTROLLER
Controller Type
Weight
Dimension
Peak Efficiency
Highest Work Temp
FOC
2 kg (5 lbs)
248mm x 128mm x 50mm
92%
100°
POWER
Nominal Voltage
Maximum Speed
Nominal Torque
60V (DC)
Factory limited to 32 km/h (20 mph)
45 N.M
TRANSMISSION
Gear Ratio
Primary Transmission
Drive Transmission
8.35 (44T) / 9.18 (48T)
Gearbox
Chain
ELECTRONIC
Battery Pack
Battery Size
Battery Weight
Battery Cells
Display
Regenerative Braking
60V 45AH
170mm x 140mm x 380mm
12.85 kg (28.3 lbs)
LG Brand 21700 cell (5000 MAH/cell)
Speed, battery level, voltage, odometer
4-level adjustment
BATTERY
The Sting MX4 is powered by a strong 60V/45Ah lithium-ion power pack (2,700 watt-hours). Easily swappable, the battery pack can be removed and replaced with another fully charged power pack in seconds for limitless range. With electric auto-grade LG 21700 lithium-ion battery cells, state of the art programmed battery management system (BMS) and optimized internal structure, this battery pack ensures the bike brings you safe, hi performance off-road riding.
CONTROLLER
With the high-quality hardware, superb layout and intelligent programming, the Sting MX4 controller has an extraordinary level of transient current impact resistance, ultra strong anti-interference, high-precision EABS voltage and discharge current control, error inspection, high and low temperature protection, anti-runaway, and smart energy regeneration. This guarantees a powerful, exciting, and safe riding experience with respectable range.
DISPLAY
The display screen features a high-contrast OLED display that offers riders a clear info display with low power consumption. With CAN communication, the dash can transfer data with the BMS and controller. The display menu provides a range of information, which include top/average speed, range, battery data, riding mode, error codes, regen level and more. The dash is also adjustable if using different wheels, sprocket size, regen levels, and can display in km or miles.
POWERTRAIN
The customized combination powertrain design is just perfect for the light weight electric MX bike. The high efficiency brushless internal permanent magnet mid-drive motor, with top-class magnet material and advanced processing, is available to output 45N.m peak torque. With exquisitely crafted high accuracy gears, the gearbox runs even quieter and is much more durable than any belt drive systems. It’s time to say goodbye to that broken belt anxiety.
Please note that all motorcycles sold by Talaria or its dealers are for off-road use. These vehicles may not comply with certain national, federal, provincial and/or local laws or regulations. The buyer has the duty to inform himself about the various possible/applicable restrictions concerning the use of such a type of product, depending on the place where they are. The buyer assumes full responsibility for the use they decide to make of it and the possible associated consequences.
